Asustor AS6504RS 4 Bay NAS,Intel ATOM C3538 Quad-Core, 8GB DDR4, GbE x 2, 2.5 GbE x 2, PCIe Gen3 (by 8 x1 - 4 link), USB 3.2 Gen 1 x 4

For small and medium businesses

• Intel Atom C3538 2.1GHz Quad-Core CPU
• 8 GB DDR4-2133 - 128 GB maximum
• Two Gigabit Ethernet and two 2.5-Gigabit Ethernet ports. Can provide up to 5 gbps when aggregated.
• Supports Wake-on-LAN and Wake-on-WAN
• Complete iSCSI/IP-SAN and NFS support - Supports VMware, Citrix and Hyper-V - Supports virtual machines and Docker applications
• Supports ACL and AD. Improves business application efficiency.
• PCIe slot for 10-Gigabit Ethernet card

	Memory Module Pre-installed	8GB (1x 8GB)
	Total Memory Slots	4
	Memory Expandable up to	128GB (4x 32GB)

Support mixed capacity
	Flash Memory	8GB eMMC
Storage	Drive Bays	4
	Compatible Drive Type

3.5" SATA HDD 2.5" SATA HDD 2.5" SATA SSD
	Maximum Drive Bays with Expansion Unit	20
External Ports	Expansion	4x USB 3.2 Gen 1
	Network	2x Gigabit Ethernet (1G/100M) ; 2x 2.5 Gigabit Ethernet (2.5G/1G/100M)
	PCIe Expansion Slots	PCIe 3.0 x8 slot (black, x4 link)
	HDMI Output	N/A
Others	System Fan	2x 40mm
	LCD Panel
	Power Supply Unit / Adapter	AS6504RS: 250W x1 AS6504RD: 250W x2 AS6504RS x1 / AS6504RD x2
	Input Power Voltage	100V to 240V AC
	Redundant power supply
	Service LED Indicator
	Certification	FCC, CE, VCCI, BSMI, C-TICK, KCC, BIS
	Warranty	3 Years
Operation	Power Consumption	AS6504RS: 47.7W (Operation) 28.4W (Disk Hibernation); AS6504RD: 65W (Operation) 42.4W (Disk Hibernation);

	Noise Level	-
	Operation Temperature	0°C~40°C (32°F~104°F)
	Humidity	5% to 95% RH
Size and Weight	Size	44(H) x 439(W) x 515(D) mm
	Weight	AS6504RS: 7.85kg / 17.27 lbs; AS6504RD: 9.3 kg / 20.46 lbs



Hardware Specifications
CPU	CPU Model	Intel ATOM C3538
	CPU Architecture	x64 64-bit
	CPU Frequency	Quad-Core 2.1GHz
Memory	Memory	8GB SO-DIMM DDR4
